Mini Digital Torque Screwdriver
modèle :
DTS-SHSD Series
DTS-SHSD Series
Mini Digital Torque Screwdriver
Mini Digital Torque Screwdriver
DTS-SHSD Series
Mini Digital Torque Screwdriver
● Accuracy: CW: ±3% ; CCW: ±4%
● Units: cNm, Kg.cm, lb-in
● Operating Temperature: -10°C - 60°C
● Storage Temperature: -20°C - 70°C
● Humidity: Up to 90% non-condensing
● Battery: AAA x 2
● Battery Life(standard mode): 1 year
● Battery Life(continuous operation): 110 hrs.
● Drop Test: 1m
● Shaking Test: 10G
● Service life test: 10000 cycles
● Environmental test: PASS
● EMC test: PASS
Mini Digital Torque Screwdriver
● Accuracy: CW: ±3% ; CCW: ±4%
● Units: cNm, Kg.cm, lb-in
● Operating Temperature: -10°C - 60°C
● Storage Temperature: -20°C - 70°C
● Humidity: Up to 90% non-condensing
● Battery: AAA x 2
● Battery Life(standard mode): 1 year
● Battery Life(continuous operation): 110 hrs.
● Drop Test: 1m
● Shaking Test: 10G
● Service life test: 10000 cycles
● Environmental test: PASS
● EMC test: PASS
|
ITEM NO. |
Driver |
Bit |
Max. |
Setting Range |
Min. |
Max. Torque
Load/ |
Length |
Weight |
|
cNm |
cNm |
cNm |
Nm |
mm |
kg |
|||
|
DTS-SHSD50 |
1/4" |
Hex |
50 |
5 - 50 |
0.1 |
12 / 10 |
234 |
0.18 |
|
DTS-SHSD200 |
1/4" |
Hex |
200 |
10 - 200 |
0.1 |
12 / 10 |
234 |
0.18 |
|
DTS-SHSD400 |
1/4" |
Hex |
400 |
20 - 400 |
0.1 |
12 / 10 |
234 |
0.18 |
