VAP-A31U
1" Double Diaphragm Pump
(Aluminum Alloy Pump)


● Liquid Inlet & Outlet: 1" NPT
● Air Inlet & Outlet: 3/8" NPT
● Aluminum Alloy Pump
● Wetted Body: Aluminum
● Diaphragm: UPE+Santoprene
● Valve Seat: SUS304
● Ball Valve: Teflon
● Certificates: CE/ Ex II 2 GD c IIB T4~T5

VAP-A31U
1" Double Diaphragm Pump
(Aluminum Alloy Pump)


● Dimension: (L)29 x (W)26 x (H)39 cm
● Min. Pressure for starting air valve 1.2 Bar
● Max.Air Supply Pressure: 8.3 Bar (125 psi)
● Max Speed 400 CPM
● Flow of each cycle: 0.45 L
● Max. Air Consumption: 960 NL/min
● Solid Limit: Φ3.0 mm
● Inlet Lift (Deep): 6 m-Wet / 3.7 m-Dry
● Max Flow Rate: 47.49 GPM (180 LPM)
● Weight 10 kg
